EBS MicroBass 3. Your tone, wherever you play.
Ever come to a gig without your amp and had to play something that sounds nothing like your own gear? Whether on a loaner amp, a silent stage, or in a recording situation, the MicroBass 3 bass preamp will always have your ‘bassic’ needs covered.
The MicroBass 3 is a fully analog, 2-channel preamp/DI box inspired by the legendary Fafner II amp. It’s engineered in Sweden with top-tier components and designed for maximum performance.
Unlike many other preamp pedals, the MicroBass 3 converts 9V DC power to an internal operating voltage of ±15 V, providing headroom like that of high-end studio equipment. That makes a big difference for bass players who play slap bass, aggressive fingerstyle, use 5- or 6-string basses, or active 18V onboard preamps.
With clean and drive channels, two balanced XLR outputs, a built-in tuner, compressor, stereo effects loop, headphone amp, and AUX input, the MicroBass 3 is equally at home on stage, in the studio, or wherever you plug in and play.
Features
Preamp
100% analog professional preamp
Channels
Dual channels – Clean and Drive
Channel Configuration
Run in parallel or series
Blend Control
Blend control for the drive
Balanced XLR Output
Dual Balanced XLR-out (pre & post EQ or Stereo)
Effects Loop
Effects loop (mono or stereo)
Filters
Character and Bright filters (clean channel)
Drive Engines
HI or LO gain drive engines
Drive Type
Thin or Deep type (drive channel)
Additional Outputs
Tuner, Aux-input, Headphones out
Input Impedance
10 Mohms input impedance (main input)
Power Supply
9V DC, 450 mA required (power supply included)
Manual
Download the manual (pdf)
Specs
Clean Channel:
Input Impedance:
Parallel mode 1.5 Mohms, 44 pF; Serial mode 10 Mohms, 22 pF
Gain:
Gain Range min/max -∞ / +30 dB; Gain Peak LED +10 dBv
Frequency Response:
+0 / -3 dB 20 – 20,000 Hz
Character:
Filter Type Shelving High/Low Pass; Gain: Lo +6 dB @ 80 Hz, Mid -2 dB @ 900 Hz, Hi +3 dB @ 7.5 kHz
Bright:
Filter Type Shelving; Gain: +10 dB @ 10 kHz
Filter Section:
Bass Filter: Type 12 dB/oct. Shelving, Gain Range +/- 18 dB @ 60 Hz;
Middle Filter: Type Bandpass Filter, Frequency Range 50 – 5,000 Hz, Q – Boost 0.5 – 1.3, Q – Cut 0.5 – >5, Gain Range +/- 12-15 dB;
Treble Filter: Type Shelving, Gain Range +/- 18 dB @ 8 kHz
Comp/Limit:
Comp Gain 0 dB, Attenuation max 24 dB, Compression Ratio max 3:1, Attack (80%) typ <10 ms, Release (80%) typ 100 ms
Drive Channel:
Input Impedance:
1.8 Mohms, 22 pF
Drive:
Gain Range 40 dB
Engines:
Lo: Type 2nd harmonics soft;
Hi: Type Symmetrical 2-stage with +18 dB gain
Drive type:
Thin/Normal/Deep Pre Drive EQ
Filter Section:
Tone Filter: Type 6 dB/oct. Low Pass, Frequency Range 700 – 20k Hz;
Middle Filter: Type Bandpass Filter, Frequency Range 100 – 4,500 Hz, Q 1.2, Gain Range +/- 15 dB
Effects Loop
Loop Signal Level nominal -10 dBv, Gain Unity (1:1), Output Impedance <100 ohms, Input Impedance >200 kohms, 22 pF
Phones Out
Recommended Impedance 32 – 200 ohms
Aux Input
Input Impedance 20 kohms, Nominal Level -10 dBv
Output
Output Impedance <1 kohms, Signal Level nominal 0 dBv
Balanced Outputs
Output Level nominal -20 dBv, XLR Connections 1-GND, 2-Hot, 3-Cold, Options Pre/Post EQ, L/R Ch. in stereo mode
Auxiliary Info
Power Requirements Idle 450mA @ 9V, Max 750mA @ 9V (with headphones at max output level)
Dimensions (WxDxH)
max 168 x 124 x 53 mm / 6.6″ x 4.9″ x 2.1″
Weight
660 g (1.5 lbs.)
